TCD2013
The Deutz TCD 2013 series is an advanced water-cooled, inline 4-cylinder and 6-cylinder diesel engine. As a comprehensive upgrade to the 1013 series, this engine is equipped with the advanced Deutz Common Rail (DCR) system or high-pressure unit pumps, combined with the EMR3 intelligent electronic management system for optimized combustion efficiency. Complying with Tier 3 / Stage IIIA emission standards, this engine series offers robust power, rapid dynamic response, low operating noise, and excellent fuel economy. It is widely installed in medium and heavy-duty excavators, wheel loaders, road rollers, and large agricultural tractors.
Specifications
Engine TypeInline 4-cylinder or 6-cylinder, 4-stroke, water-cooled diesel engine (available in 2-valve and 4-valve versions)
Displacement4.76 liters
Bore × Stroke108 mm × 130 mm
AspirationTurbocharged & Aftercooled
Emission StandardCompliant with EPA Tier 3 / EU Stage IIIA
